| Image Sensor: | 1/1.8" 8MP CMOS |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/100,000 s |
| Lens: | 4mm F1.6 fixed lens |
| Day&Night: | Dual Light(White Light+IR LED Light) with auto switch |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Motion Detection | Support |
| Privacy Protection | Support(4 Self-customized Areas) |
| Water-Proof: | IP66 |
| Illumination for Infrared Switching: | 0.5~3Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON) |
| IR Range: | / |
| Compression Standard |
| Video Compression: | H.265/H.264/MJPEG |
| Video Bit Rate: | 32Kbps~12288Kbps(CBR/VBR Selectable) |
| Audio Compression: | G711U/G711A |
| Dual Streams: | Yes |
| Triple Streams: | Yes |
| Image |
| Max. Image Resolution: | 3840*2160@20fps(8MP) |
| Frame Rate: | 50/60Hz: Max.: 3840*2160@20fps |
| Sub Stream: | 50Hz/60Hz: Max. (800*488/704*576/640*360/352*288)@20fps |
| Third Stream(Mobile Stream): | 50/60Hz: (1080P/720P/CIF)@5fps |
| Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | Auto(Passive Mode)/Day/Night/Auto(Active Mode)/Time |
| Network |
| Network Protocols: | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, RTMP,DDNS, IP Search(Support Danale IP camera, DVR, NVS etc.) |
| General Function: | Anti-Flicker, heartbeat, password protection, privacy mask, Watermark |
| System Compatibility: | ONVIF(17.06 ) profile S/Danale(P2P) |
| On-line Viewing | Max. Support 6 Users Simultaneously |
| Interface |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
| DC Power Plug: | DC Power Female Interface |
| General |
| Operating Conditions: | -10 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 8W
(When the infrared lamps turn on) |
| Dimensions(W×D×H) | 195mm×70mm×63mm |
| Weight: | 0.45KG |
