2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
Products
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
  • Product features
  • Product parameters
  • Related downloads

• 2MP/ 4MP/ 5MP/ 8MP optional

• F1.0 lens available

• H.265/H.264 8MP IP/Network Full Color Starlight Turret Camera
• Up to 8 megapixel high resolution
• Max. 3840*2160@20fps(50Hz/60Hz)
• Support RTSP&Onvif(17.2 with profile S)
Compatible with many third-party NVRs and CMS
• Support multiply Web Browsers: IE/Firefox/Chrome/Safari etc.
• P2P Cloud service
• Free PC Client Software and Smartphone APP(P2P)
• Support Alarm Snapshot to Email and FTP
• Day/Night, AWB/MWB,BLC, 3D-DNR,Shutter, IR-CUT, D-WDR,Mirror, Image Flip etc. Functions
• Water-proof: IP66

Image Sensor:1/1.8” CMOS Sensor
Signal System:PAL/NTSC
Min. Illumination:Color: 0.01lux @(F1.0, AGC ON)
Shutter Time:1/25 s to 1/10,000 s
Lens:3.6mm fixed lens（2.8mm Optional )
Day&Night:2pcs Warm LED
Image Enhancement:BLC/3D DNR/WDR
Motion Detection:Support
Privacy Protection:Support(4 Self-customized Areas)
Smart function:Humanoid detection
LED Light DistanceWarm light 20m
Wather-Proof:IP66
Compression Standard
Video Compression:H.265/H.264
Video Bit Rate:512Kbps~6144Kbps(main stream H.265)
64kbps~2048Kbps(sub stream H.265)
Dual Streams:Yes
Triple Streams:No
Image Resolution:main stream:3840x2160(8MP)/2560*1440(4MP)/920x1080(1080p)
sub stream:720x480(D1)/640x480(VGA)/640x360/352x288(CIF)
Frame Rate:main stream:20fps(8MP) max.
sub stream:25fps max
Stream:two streams
Image Settings:3D NR,WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App
Day/Night modesupport Full color mode
Audio
Audio Compression:G711U/G711A/AAC
Audio Bitrate64K(G711)/16k(AAC)
Audio In/Out：Optional (RCA socket)
Build-in MIC：Yes
Volnume adject：Yes
Network
Network Protocols:Http/Https, TCP/IP, IPv4/v6, UPNP, RTSP/RTMP,FTP, UDP, SMTP, NTP, DHCP, DNS,
DDNS,IP Search(Support P2P, NVR, NVS etc.)
General Function:Anti-Flicker, heartbeat, password protection, privacy mask, Watermark
System Compatibility:ONVIF(17.2 with profile S)
On-line ViewingMax. Support 2 Users Simultaneously
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet Interface
Audio Interface:RCA Audio input/output  Interface (Optional)
Alarm in/out interface：Support（1ch） （Optional）
SD card interfaceSupport TF card（micro TF card，up to 128G） （Optional）
DC Power Plug:DC Power Femate Interface/POE(optional)
General
Operating Conditions:
Humidity 95% or less (non-condensing)
Power Supply:12 V DC ± 10%/PoE(Optional)
Power Consumption:12 VDC ± 10%, Max Power Comsumption Less than 8W
 (When the infrared lamps turn on)
Weight:0.56KG


No Data
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera
2MP/ 4MP/ 5MP/ 8MP PoE Dome Camera

• 2MP/ 4MP/ 5MP/ 8MP optional

• F1.0 lens available

• H.265/H.264 8MP IP/Network Full Color Starlight Turret Camera
• Up to 8 megapixel high resolution
• Max. 3840*2160@20fps(50Hz/60Hz)
• Support RTSP&Onvif(17.2 with profile S)
Compatible with many third-party NVRs and CMS
• Support multiply Web Browsers: IE/Firefox/Chrome/Safari etc.
• P2P Cloud service
• Free PC Client Software and Smartphone APP(P2P)
• Support Alarm Snapshot to Email and FTP
• Day/Night, AWB/MWB,BLC, 3D-DNR,Shutter, IR-CUT, D-WDR,Mirror, Image Flip etc. Functions
• Water-proof: IP66
