| Image Sensor: | 1/2.9'' Cmos Sensor |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/10,000 s |
| Lens: | 2.8mm fixed Lens*2 |
| Day&Night: | IR cut filter with auto switch |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Human Body Detection | Support |
| Privacy Protection | Support(4 Self-customized Areas) |
| Wather-Proof: | IP66 |
| Illumination for Infrared Switching: | 1~5Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON) |
| IR Range: | 4PCS LEDS//(IR: 30m) + (White Light :20m) |
| Compression Standard |
| Video Compression: | H.265/H.264 |
| Video Bit Rate: | 512Kbps~12288Kbps(main stream H.265)
64kbps~1024Kbps(sub stream H.265) |
| Audio Compression: | G711U/G711A/AAC |
| Dual Streams: | Yes |
| Triple Streams: | No |
| Image |
| Max. Image Resolution: | 4096*1944@20fps(8MP) |
| Frame Rate: | 8MP ( 4096*1944), Max 20fps.MAX main stream
1280*360, Max 20fps .MAX sub stream |
| Image Settings: | 3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness
adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | EXT/Day/Night/Auto/Time |
| Audio |
| Line IN/line OUT | Support（1ch） |
| Volnume adject | Yes |
| Built-in Mic | Yes |
| Built-in Speaker | Yes |
| Network |
| Network Protocols: | HTTP, TCP/IP, IPv4/v6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,
DDNS,IP Search(Support P2P, NVR, NVS etc.) |
| General Function: | Anti-Flicker, heartbeat, password protection, privacy mask, Watermark |
| System Compatibility: | ONVIF(17.2 with profile S) |
| On-line Viewing | Max. Support 2 Users Simultaneously |
| WIFI function | Built-in（optional） |
| Protocol standard | IEEE 802.11b/g/n |
| Frequency Range | 2.402GHz - 2.483Ghz |
| Channel bandwidth | 20/40MHZ |
| Safety | WPA/WPA2，WPA-PSK/WPA2-PSK，WPS |
| Transmission distance | 100 meters (without obstacles) |
| Cloud storage | Yes |
| antenna | external 5dB antenna (SMA socket) |
| Interface |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| RCA Audio Interface: | RCA Audio input/output Interface (Optional) |
| Alarm in/out interface： | Support（1ch） （Optional） |
| SD card interface | Support TF card（micro TF card，up to 256G） |
| DC Power Plug: | DC Power Femate Interface |
| General |
| Operating Conditions: | -10 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: | 12 VDC ± 10%, Max Power Comsumption Less than 8W
(When the infrared lamps turn on) |
